How to use LDR as a Light Sensor with Arduino.

How to use LDR as a Light Sensor with Arduino.
A light sensor with Arduino  is a simple demonstration of how Arduino can be used in home automation, in this case controlling the lighting of bulbs depending on the amount of light in a given area. In this project we are using a LDR (Light Dependent Resistor) to act as a photosensor so that when there is light the LED will turn off and when it gets dark the LED turns on automatically.

What is an LDR (Light Dependent Resistor)?

light sensor with arduino LDR
An LDR is a component that has a (variable) resistance that changes with the light intensity that falls upon it. This allows them to be used in light sensing circuits.The most common type of LDR has a resistance that falls with an increase in the light intensity falling upon the device.
LDRs are used mainly as sensors in for lighting switches to control light in homes and streets. They are also used as camera shutter controls.The LDR would be used to measure the light intensity which then adjusts the camera shutter speed to the appropriate level.

Setup of Light Sensor with Arduino

ldr sensor_bb
From the setup, we have a voltage divider cicuit using LDR and 100k resistor. The voltage divider output is fed to the analog pin A0 of the Arduino. The analog Pin senses the voltage and gives some analog value to Arduino. The analog value changes according to the resistance of LDR. So, as the light falls on the LDR the resistance of it get decreased and hence the voltage value increase.

CODE

int led=3; // led at pin3

void setup(){
pinMode(led,OUTPUT);
}
void loop(){
int sensor_value=analogRead(A0); //read value from sensor
if(sensor_value<150){    //setting a threshold value
digitalWrite(led,HIGH);
}
else{
digitalWrite(led,LOW);
}

This code for the Light sensor with Arduino enables reading the voltage analog value through the A0 pin of the Arduino. This analog Voltage will be increased or decreased according to the resistance of LDR.
A condition is set for darkness and brightness. From the code above, if the value is less than 150 then it is dark and the LED turns ON. If the value is greater than 150 then it is bright and the LED turns OFF.
